Power You Control
Briggs & Stratton 71212 100-Amp Automatic Transfer Switch w/ 16-Circuit Load Center
Product Details
Brand:
Briggs & Stratton
Features
| Type | Amp Rating | Circuits | Voltage | Enclosure |
| Load Center | 100 | 16 | 120/240 Single Phase | Nema 3R |
- Maximum Safety, Comfort and Efficiency
- Compatible with 12-20kW Intelligen Standby Generator
- Rated at 100-Amps @ 240V
- 16-Circuit Design (Breakers Not Included)
- Allows you to select your priority circuits
- Manage up to 2 AC units
- AC Power Control Module (ACCM)
- Imprints starting wattage of your AC in the control board
- Monitors usage/watts until your AC can be started
- Assures usage while preventing overload
- Built-In AC Delay For AC Start-up
- Allows for pressure to bleed off AC motor
- Makes start-up less power intensive
- Nema 3R Enclosure
- Flexibility in mounting locations - indoor or outdoor
- Wiring NOT Included
- Breakers NOT Included
Specifications
Product Specs
| Voltage | 120/240 Single Phase |
| Frequency | 60 Hertz |
| Rated Amps | 100 Amps |
| Enclosure | NEMA 3R |
| Number of Circuit Breakers | 16 |
| Transfer Switch Style | Standard Installation |
| ATS Load Prioritizing | Built-In |
| ATS Load Shedding | Built-In |
| ATS Service Disconnect | No |
| Max Utility Input | 100 Amps |
| Max Generator Input | 100 Amps |
| Maximum Wattage | 24000 Watts |
| CUL Listed | Yes |
Overview
| Weight | 37 lbs |
| Made in USA | Yes |
| Consumer Warranty | 5 Years |
| Product Length | 24 Inches |
| Product Width | 14 Inches |
| Product Height | 6 Inches |
